Sovran_SystemsOS
A declarative, self-hosted operating system built on NixOS.
Overview
Sovran_SystemsOS is a fully integrated NixOS configuration that transforms a single machine into a personal cloud, communications hub, Bitcoin node, web server, and daily-use desktop — all managed declaratively.
Every service is pre-wired: reverse proxy routing, database initialization, firewall rules, automated backups, and inter-service communication are handled out of the box. Moreover, you can activate the other custom packages; the system does the rest.
Architecture
Sovran_SystemsOS is structured as a set of NixOS modules exposed via a flake. A remote machine consumes the flake and selectively enables features through a simple configuration interface.
Repository Main Flake (flake.nix)
└── Sovran_SystemsOS flake (nixosModules.Sovran_SystemsOS)
├── configuration.nix/ # Base system
│ ├── gnome Desktop # Gnome Desktop Interface
│ ├── caddy # Reverse proxy + HTTPS
│ ├── nextcloud # Cloud storage
│ ├── wordpress # CMS / publishing
│ ├── element # Matrix Synapse via Element Messaging App
├── modules/
│ ├── bitcoinecosystem.nix # Bitcoin Core / Knots / BTCPay Server / Bitcoin Lightning
│ ├── bip110.nix # Bip110 Node Consensus Policy
│ ├── element-calling.nix # Matrix Synapse via Element + Element Voice and Video Calling
│ ├── haven.nix # Nostr relay
│ ├── mempool.nix # Mempool explorer
│ ├── rdp.nix # Remote desktop (RDP)
│ ├── vaultwarden.nix # Password management
├── nix-bitcoin integration
├── bitcoin clients integration
│ ├── sparrow wallet # Trusted and Standard Open Source Bitcoin Wallet
│ ├── bisq/bisq2 # Non KYC Bitcoin Buying and Selling
├── agenix (secrets management)
└── nixvim
Features
Feature Toggles
Every major service is gated behind a feature flag. Enable only what you need:
# custom.nix
{ config, pkgs, lib, ... }:
{
sovran_systemsOS = {
features = {
bip110 = lib.mkForce true;
element-calling = lib.mkForce true;
haven = lib.mkForce true;
mempool = lib.mkForce true;
rdp = lib.mkForce true;
};
nostr_npub = "pasteyournpubhere";
};
}
No unnecessary services run. No wasted resources.
Service Stack
| Category | Service | Description |
|---|---|---|
| Web | Caddy | Automatic HTTPS, reverse proxy for all services |
| Cloud | Nextcloud | File storage, sync, and collaboration |
| CMS | WordPress | Self-hosted publishing and content management |
| Passwords | Vaultwarden | Bitwarden-compatible password vault |
| Messaging | Element/Matrix Synapse | Federated, decentralized messaging backend |
| Video/Voice Calling | Element Video and Voice Calling | Decentralized Voice Over IP for Matrix with optional TURN/STUN |
| Bitcoin | Bitcoin Core / Knots | Full node with optional BIP-110 consensus policy |
| Bitcoin Lightning | LND Full node connected over TOR | |
| Payments | BTCPay Server | Self-hosted Bitcoin payment processor |
| Explorer | Mempool | Bitcoin mempool visualizer and block explorer |
| Nostr | Haven | Nostr relay server |
| Remote Access | GNOME Remote Desktop | RDP access with auto-generated TLS and credentials |
Security
- SSH hardened — password authentication disabled by default
- Fail2ban — active on https
- Agenix — encrypted secrets management integrated into the flake
- Tor — integration into the bitcoin ecosystem
- Firewall — ports managed per-module; only enabled services are exposed
Reliability
- Automated backups via rsnapshot
- Scheduled maintenance via systemd timers
- Database initialization handled declaratively
- Reproducible builds — the entire system is defined in code and can be rebuilt or migrated to new hardware at any time
Network Configuration
Sovran_SystemsOS hosts public-facing services (Wordpress, Element/Element Calling, Nextcloud, BTCPayserver, Haven Relay, and Vaultwarden) that require inbound connections from the internet. To make these services accessible outside your local network, you must configure port forwarding on your home router.
Before deploying, ensure you have:
- Access to your router's administration interface (typically at
192.168.1.1or192.168.0.1) - The ability to create port forwarding rules
- The local/private IP address of the machine running Sovran_SystemsOS
- The external public IP address of the machine running Sovran_SystemsOS
Required port forwards (depending on enabled features):
Forward each port to the private IP address of your Sovran_SystemsOS machine. Only forward ports for services you have enabled.
Tip: Assign a static IP or DHCP reservation to your Sovran_SystemsOS machine so the forwarding rules remain valid after reboots.
Note: If your ISP uses CGNAT (Carrier-Grade NAT), standard port forwarding will not work. Contact your ISP to request a public IP address.
Installation
Full Guide
👉 DIY Install Sovran_SystemsOS
Requirements
| Resource | Minimum | Recommended |
|---|---|---|
| CPU | 4 cores | 8+ cores |
| RAM | 16 GB | 32+ GB |
| Storage | 512 GB SSD + 4 TB SSD | 2GB SSD + 4+ TB SSD (Bitcoin node requires significant disk) |
| Network | 100Mbs Down 20Mbs Up + No need for DDNS if domains are brought through https://njal.la | 1Gbs Up and 1 Gbs Down + No need for DDNS if domains are brought through https://njal.la |
Community
| Channel | Link |
|---|---|
| General Chat | #sovran-systems:anarchyislove.xyz |
| DIY Support | #DIY_Sovran_SystemsOS:anarchyislove.xyz |
License
See LICENSE for details.
Project Philosophy
Sovran_SystemsOS exists to provide a complete, self-hosted infrastructure stack that eliminates dependency on third-party platforms. It is opinionated by design — services are pre-integrated so you spend time using your system, not assembling it.
This is not a toolkit. It is a working system.
You retain full visibility into every module, every service definition, and every configuration choice. Nothing is hidden. Everything is reproducible.
Be Digitally Sovereign
