Sovran_SystemsOS is a fully integrated NixOS configuration that transforms a single machine into a personal cloud, communications hub, Bitcoin node, web server, and daily-use desktop — all managed declaratively.

It comes preinstalled on The Sovran Pro

Every service is pre-wired: reverse proxy routing, database initialization, firewall rules, automated backups, and inter-service communication are handled out of the box. Moreover, you can activate the other custom packages; the system does the rest.

Architecture

Sovran_SystemsOS is structured as a set of NixOS modules exposed via a flake. A remote machine consumes the flake and selectively enables features through a simple configuration interface.

Repository Main Flake (flake.nix)
  └── Sovran_SystemsOS flake (nixosModules.Sovran_SystemsOS)
        ├── configuration.nix/       # Base system
        │   ├── gnome Desktop        # Gnome Desktop Interface
        │   ├── caddy                # Reverse proxy + HTTPS
        │   ├── nextcloud            # Cloud storage
        │   ├── wordpress            # CMS / publishing
        │   ├── element              # Matrix Synapse via Element Messaging App
        ├── modules/
        │   ├── bitcoinecosystem.nix # Bitcoin Core / Knots / BTCPay Server / Bitcoin Lightning
        │   ├── bip110.nix           # Bip110 Node Consensus Policy
        │   ├── element-calling.nix  # Matrix Synapse via Element + Element Voice and Video Calling
        │   ├── haven.nix            # Nostr relay
        │   ├── mempool.nix          # Mempool explorer
        │   ├── rdp.nix              # Remote desktop (RDP)
        │   ├── vaultwarden.nix      # Password management
        ├── nix-bitcoin integration
        ├── bitcoin clients integration
        │   ├── sparrow wallet       # Trusted and Standard Open Source Bitcoin Wallet
        │   ├── bisq/bisq2           # Non KYC Bitcoin Buying and Selling
        ├── agenix (secrets management)
        └── nixvim

Features

Feature Toggles

Custom Add-On Guide

Every major service is gated behind a feature flag. Enable only what you need:

# custom.nix
{ config, pkgs, lib, ... }:

{

  sovran_systemsOS = {
    features = {
        bip110          = lib.mkForce true;
        element-calling = lib.mkForce true;
        haven           = lib.mkForce true;
        mempool         = lib.mkForce true;
        rdp             = lib.mkForce true;
    };
    nostr_npub = "pasteyournpubhere";
  };

}

No unnecessary services run. No wasted resources.

Service Stack

Category	Service	Description
Web	Caddy	Automatic HTTPS, reverse proxy for all services
Cloud	Nextcloud	File storage, sync, and collaboration
CMS	WordPress	Self-hosted publishing and content management
Passwords	Vaultwarden	Bitwarden-compatible password vault
Messaging	Element/Matrix Synapse	Federated, decentralized messaging backend
Video/Voice Calling	Element Video and Voice Calling	Decentralized Voice Over IP for Matrix with optional TURN/STUN
Bitcoin	Bitcoin Core / Knots	Full node with optional BIP-110 consensus policy
Bitcoin Lightning	LND	Full LND Node Connected over Tor intergrated into BTCPay Server
Payments	BTCPay Server	Self-hosted Bitcoin payment processor
Explorer	Mempool	Bitcoin mempool visualizer and block explorer
Nostr	Haven	Nostr relay server
Remote Access	GNOME Remote Desktop	RDP access with auto-generated TLS and credentials

Security

SSH hardened — password authentication disabled by default
Fail2ban — active on https
Agenix — encrypted secrets management integrated into the flake
Tor — integration into the bitcoin ecosystem
Firewall — ports managed per-module; only enabled services are exposed

Reliability

Automated backups via rsnapshot
Scheduled maintenance via systemd timers
Database initialization handled declaratively
Reproducible builds — the main system is defined in code and can be rebuilt to match most systems

Network Configuration

Sovran_SystemsOS hosts public-facing services (Wordpress, Element/Element Calling, Nextcloud, BTCPayserver, Haven Relay, and Vaultwarden) that require inbound connections from the internet. To make these services accessible outside your local network, you must configure port forwarding on your home router.

Before deploying, ensure you have:

Access to your router's administration interface (typically at 192.168.1.1 or 192.168.0.1)
The ability to create port forwarding rules
The local/private IP address of the machine running Sovran_SystemsOS
The external public IP address of the machine running Sovran_SystemsOS

Required port forwards (depending on enabled features):

Forward each port to the private IP address of your Sovran_SystemsOS machine. Only forward ports for services you have enabled.

Tip: Assign a static IP or DHCP reservation to your Sovran_SystemsOS machine so the forwarding rules remain valid after reboots.

Note: If your ISP uses CGNAT (Carrier-Grade NAT), standard port forwarding will not work. Contact your ISP to request a public IP address.

Installation

Full Guide (A bit outdated as of now... will be working on a smoother DIY soon)

👉 DIY Install Sovran_SystemsOS

Requirements

Resource	Minimum	Recommended
CPU	4 cores	8+ cores
RAM	16 GB	32+ GB
Storage	512 GB SSD + 4 TB SSD	2GB SSD + 4+ TB SSD (Bitcoin node requires significant disk)
Network	100 Mbs Down/20 Mbs Up + No need for DDNS if domains are brought through https://njal.la	1 Gbs Down/1 Gbs Up + No need for DDNS if domains are brought through https://njal.la

Community

Channel	Link
General Chat	#sovran-systems:anarchyislove.xyz
DIY Support	#DIY_Sovran_SystemsOS:anarchyislove.xyz

License

See LICENSE for details.

Project Philosophy

Sovran_SystemsOS exists to provide a complete, self-hosted infrastructure stack that eliminates dependency on third-party platforms. It is opinionated by design — services are pre-integrated so you spend time using your system, not assembling it.

This is not a toolkit. It is a working system.

You retain full visibility into every module, every service definition, and every configuration choice. Nothing is hidden. Everything is reproducible.

Be Digitally Sovereign
